Oilgear K516175-C13 Seal Kit: USA EPR Seals
Need other parts for this rebuild?
We have access to 30,000+ parts that aren't listed on the site. Send us your part list and we'll quote it.
Seeing "Request a quote" on a part? That doesn't mean we don't have it. Send us the part number and we'll get back to you with price and availability.
Request a quoteOilgear K516175-C13 Seal Kit is a new OEM or aftermarket equivalent replacement for Oilgear PVG piston pumps, supplied by RestoPower. Built to meet or exceed the original Oilgear specification for a precise, dependable fit.
What is in this kit. Oilgear lists K516175-C13 as containing items 007,010,011,404,405(2),406,407(2),411 Control 330,313 from the Oilgear PVG-100 / -130 (C-Frame) parts drawing. Position numbers match the callouts on the exploded view in the PVG-100 / -130 (C-Frame) parts catalog.
Specifications
| OEM Part Number | K516175-C13 |
| Part Type | Seal Kit |
| Brand | OEM or aftermarket equivalent to Oilgear |
| Design Series | All |
| Factory Description | USA EPR Seals |
| Items Included | 007,010,011,404,405(2),406,407(2),411 Control 330,313 |
| Pump Series | PVG-100, PVG-130 |
| Service Bulletin | Oilgear 947019B, 947022 |
| Condition | New |
| Warranty | Backed by RestoPower expert support |
| Availability | Available to order, request a quote for current price and lead time |
Compatible With
- Oilgear PVG-100
- Oilgear PVG-130
Cross Reference
K516175-C13, Oilgear K516175-C13, K516175C13, K516175 C13
Common Applications
- Industrial hydraulic power units, machinery and machine tools
- Presses, injection molding and die casting
- Steel mill, marine and heavy process equipment
- Mobile, construction and agricultural equipment
- Pump rebuilds and scheduled overhauls
Rebuilding the Compensator Too?
K516175-C13 carries only the seals where the control bolts onto the pump (items 313 and 330). The compensator's own seals come in a separate control seal kit, chosen by the control code at the end of your model number, for example the P-1NN in PVG-065-F1UV-RDFS-P-1NN:
- P-1NN single pressure compensator: Oilgear K516183-003 control seal kit, EPR, bulletin 947551.
- P-1NN/F pressure compensator with load sense: Oilgear K516336-002 control seal kit, EPR, bulletin 947552.
- P-1NN/H horsepower limiter: Oilgear K516338-003 control seal kit, EPR, bulletin 947553.
- P-1NN/G horsepower limiter with load sense: Oilgear K516337-003 control seal kit, EPR, bulletin 947554.
- P-2 dual pressure compensator: Oilgear K516183-C21 control seal kit, EPR, bulletin 947555A.
- P-2/H dual pressure compensator with horsepower limiter: Oilgear K517107-B21 control seal kit, EPR, bulletin 947559A. Bulletin 947559A prints the PVG-048/065/075 number for this control, while Oilgear's other 2019 PVG-100/130 bulletins use K516183-C01, so we confirm it against your nameplate before ordering.
- P-C and P-K soft start: Oilgear K516183-C21 control seal kit, EPR, bulletin 947557A.
- P-C/H and P-K/H soft start with horsepower limiter: Oilgear K516183-C21 control seal kit, EPR, bulletin 947558A.
- P-A and P-B electronic pressure compensator: Oilgear K516333-001 control seal kit, Viton (Oilgear lists this control kit in Viton only), bulletin 947556.
- P-E and P-F electronic displacement control: Oilgear K520340-001 control seal kit, Viton (Oilgear lists this control kit in Viton only), bulletin TRB-47861.
- P-E/F and P-F/F electronic displacement control with load sense: Oilgear K520341-001 control seal kit, Viton (Oilgear lists this control kit in Viton only), bulletin TRB-47861.
Control pistons, springs, spools, adjusters, volume stops and end caps for each control are listed in the parts catalog under Service kits: Control. Not sure which control you have? Send the type code from your nameplate to info@restopower.com and we will match both kits.
Guides & Catalogs
Frequently Asked Questions
Will Oilgear K516175-C13 fit my pump?
It is the factory kit number Oilgear lists for the PVG-100 and related models. Rotation, port arrangement and seal material all change which kit fits, so send the full type code and serial number from your nameplate to info@restopower.com and we will confirm fitment.
Why is there no price shown?
This part is quoted rather than stocked on the shelf. Send us the part number and we will come back with current price and lead time.
Do Oilgear parts interchange with Vickers or Parker?
No. Oilgear is a separate manufacturer with its own numbering and the parts do not interchange. Note that both Oilgear and Vickers use the designation PVM, for completely different pumps.
