Vickers 3520V Tandem Vane Pump Parts Breakdown
Parts for the Vickers 3520V double (tandem) vane pump, 22 design: a 35V shaft end section (25 to 38 USgpm) and a 20V cover end section (2 to 14 USgpm), each with its own cartridge kit. From Vickers service data I-3202-S, with 20 design cartridge kits from the factory bill of materials.
99 parts across 12 categories
Source: Vickers Service Data I-3202-S (released 04-01-92); Vickers 3520V 20 design bill of materials I-3180-S; Eaton Vickers list prices 2001-2020
Tap a diagram to zoom in.
Seal Kits 2 parts
Shaft Seals 2 parts
Shafts & Keys 10 parts
Shaft #113, 14T 12/24 spline, double shaft seal
Double shaft seal shaft for 3520V suffix 211 units (Vickers release NAG-SR-74-27, Oct 1974). Vickers Quick Reference Binder, Pump Shafts (03/05/91) lists it for 3520V(Q). Not on the 22 design sheet I-3202-S. Also used in the 3520VQ.
Qty 1
Shaft #114, 14T 12/24 spline, double shaft seal
Double shaft seal shaft for 3520V suffix 211 units (Vickers release NAG-SR-74-27, Oct 1974). Vickers Quick Reference Binder, Pump Shafts (03/05/91) lists it for 3520V(Q). Not on the 22 design sheet I-3202-S. Also used in the 3520VQ.
Qty 1
Bearings 1 part
Cartridge Kits: Shaft End 8 parts
Cartridge kit, shaft end, 25 USgpm
For 3520V25 models. Left-hand rotation kit: 02-102552-L.
Qty 1
Cartridge kit, shaft end, 30 USgpm
For 3520V30 models. Left-hand rotation kit: 02-102553-L.
Qty 1
Cartridge kit, shaft end, 35 USgpm
For 3520V35 models. Left-hand rotation kit: 02-102554-L.
Qty 1
Cartridge kit, shaft end, 38 USgpm
For 3520V38 models. Left-hand rotation kit: 02-102555-L.
Qty 1
Cartridge kit, F3, shaft end, 25 USgpm
For F3-3520V25 models. Left-hand rotation kit: 02-102560-L.
Qty 1
Cartridge kit, F3, shaft end, 30 USgpm
For F3-3520V30 models. Left-hand rotation kit: 02-102561-L.
Qty 1
Cartridge kit, F3, shaft end, 35 USgpm
For F3-3520V35 models. Left-hand rotation kit: 02-102562-L.
Qty 1
Cartridge kit, F3, shaft end, 38 USgpm
For F3-3520V38 models. Left-hand rotation kit: 02-102563-L.
Qty 1
Cartridge Kits: Cover End 23 parts
Cartridge kit, cover end, 2 USgpm
For 3520V***2 models. Left-hand rotation kit: 02-102506-L.
Qty 1
Cartridge kit, cover end, 5 USgpm
For 3520V***5 models. Left-hand rotation kit: 02-102507-L.
Qty 1
Cartridge kit, cover end, 8 USgpm
For 3520V***8 models. Left-hand rotation kit: 02-102508-L.
Qty 1
Cartridge kit, cover end, 11 USgpm
For 3520V***11 models. Left-hand rotation kit: 02-102509-L.
Qty 1
Cartridge kit, cover end, 12 USgpm
For 3520V***12 models. Left-hand rotation kit: 02-102510-L.
Qty 1
Cartridge kit, cover end, 14 USgpm
For 3520V***14 models. Left-hand rotation kit: 02-102511-L.
Qty 1
Cartridge kit, F3, cover end, 2 USgpm
For F3-3520V***2 models. Left-hand rotation kit: 02-102512-L.
Qty 1
Cartridge kit, F3, cover end, 5 USgpm
For F3-3520V***5 models. Left-hand rotation kit: 02-102513-L.
Qty 1
Cartridge kit, F3, cover end, 8 USgpm
For F3-3520V***8 models. Left-hand rotation kit: 02-102514-L.
Qty 1
Cartridge kit, F3, cover end, 11 USgpm
For F3-3520V***11 models. Left-hand rotation kit: 02-102515-L.
Qty 1
Cartridge kit, F3, cover end, 12 USgpm
For F3-3520V***12 models. Left-hand rotation kit: 02-102516-L.
Qty 1
Cartridge kit, F3, cover end, 14 USgpm
For F3-3520V***14 models. Left-hand rotation kit: 02-102517-L.
Qty 1
Cartridge kit, cover end, 2 USgpm, 20 design
For 20 design 3520V***2 pumps (20 design bill of materials). Eaton lists it as **20V2***23.
Qty 1
Cartridge kit, cover end, 5 USgpm, 20 design
For 20 design 3520V***5 pumps (20 design bill of materials). Eaton lists it as **20V5***23.
Qty 1
Cartridge kit, cover end, 8 USgpm, 20 design
For 20 design 3520V***8 pumps (20 design bill of materials). Eaton lists it as **20V8***23.
Qty 1
Cartridge kit, cover end, 11 USgpm, 20 design
For 20 design 3520V***11 pumps (20 design bill of materials). Eaton lists it as 20V11***23.
Qty 1
Cartridge kit, cover end, 12 USgpm, 20 design
For 20 design 3520V***12 pumps (20 design bill of materials). Eaton lists it as 20V12***23.
Qty 1
Cartridge kit, F3, cover end, 2 USgpm, 20 design
For 20 design F3-3520V***2 pumps (20 design bill of materials).
Qty 1
Cartridge kit, F3, cover end, 5 USgpm, 20 design
For 20 design F3-3520V***5 pumps (20 design bill of materials).
Qty 1
Cartridge kit, F3, cover end, 8 USgpm, 20 design
For 20 design F3-3520V***8 pumps (20 design bill of materials).
Qty 1
Cartridge kit, F3, cover end, 11 USgpm, 20 design
For 20 design F3-3520V***11 pumps (20 design bill of materials).
Qty 1
Cartridge kit, F3, cover end, 12 USgpm, 20 design
For 20 design F3-3520V***12 pumps (20 design bill of materials).
Qty 1
Cartridge kit, F3, cover end, 14 USgpm, 20 design
For 20 design F3-3520V***14 pumps (20 design bill of materials).
Qty 1
Shaft End Cartridge Parts 10 parts
Vane kit
12 vanes and inserts. Included in shaft end cartridge kits 02-102552 to 02-102555.
Qty 1
Cover End Cartridge Parts 15 parts
Vane kit, 2/5/8 USgpm
10 vanes and inserts. Included in cover end cartridge kits 02-102506 to 02-102511.
Qty 1
Vane kit, 11/12/14 USgpm
10 vanes and inserts. Included in cover end cartridge kits 02-102506 to 02-102511.
Qty 1
Housing & Covers 9 parts
Seals & O-Rings 12 parts
Back-up ring, shaft end
Shaft end section. Included in seal kit 922859 (F3: 919304) and the shaft end cartridge kits.
Qty 1
O-ring, shaft end
Shaft end section. Included in seal kit 922859 (F3: 919304) and the shaft end cartridge kits.
Qty 1
Seal ring, shaft end
Shaft end section. Included in seal kit 922859 (F3: 919304) and the shaft end cartridge kits. Install 419674 into the body, then install the cartridge kit.
Qty 1
O-ring, shaft end
Shaft end section. Included in seal kit 922859 (F3: 919304) and the shaft end cartridge kits.
Qty 1
O-ring, F3 (Viton), shaft end
F3 (Viton) build, shaft end section. F3 counterpart of 154084.
Qty 1
O-ring, F3 (Viton), shaft end
F3 (Viton) build, shaft end section. F3 counterpart of 154101.
Qty 1
Seal ring, cover end
Cover end section. Included in seal kit 922859 (F3: 919304) and the cover end cartridge kits.
Qty 1
O-ring, cover end
Cover end section. Included in seal kit 922859 (F3: 919304) and the cover end cartridge kits.
Qty 1
Back-up ring, cover end
Cover end section. Included in seal kit 922859 (F3: 919304) and the cover end cartridge kits.
Qty 1
O-ring, cover end
Cover end section. Included in seal kit 922859 (F3: 919304) and the cover end cartridge kits.
Qty 1
Hardware 6 parts
Other Parts 1 part
