RestoPower supplies parts, seal kits and rebuild components for Oilgear hydraulic piston pumps. Oilgear built heavy duty, high pressure pumps for steel mills, presses, marine and process plant, and a lot of that equipment is still running long after the pumps went out of production. Obsolete Oilgear numbers are normal work here.
Oilgear parts catalogs, every pump family, every frame
Each catalog below is the factory parts breakdown for one pump frame: the Oilgear exploded views, every numbered item with its quantity and the kits that supply it, and the Oilgear service kit numbers with the items each kit contains. 3,031 parts and 34 exploded views in total, taken from Oilgear’s own service bulletins.
| Pump model | Displacement | Parts | Views | Bulletin |
|---|---|---|---|---|
| PVWJ-011 / -014 / -022 (A-Frame) | 11 / 14 / 22 cm³/rev | 118 | 2 | 947085 |
| PVWJ-025 / -034 / -046 (B-Frame) | 25 / 34 / 46 cm³/rev | 104 | 2 | 947085 |
| PVWJ-064 / -076 / -098 / -130 (C-Frame) | 64 / 76 / 98 / 130 cm³/rev | 111 | 2 | 947085 |
| PVM-011 / -014 / -022 (A-Frame) | 11 / 14 / 22 cm³/rev | 236 | 3 | 947070-B |
| PVM-025 / -034 / -046 (B-Frame) | 25 / 34 / 46 cm³/rev | 245 | 3 | 947070-B |
| PVM-065 / -075 (B-Frame) | 65 / 75 cm³/rev | 218 | 3 | 947070-B |
| PVM-064 / -076 / -098 / -130 (C-Frame) | 64 / 76 / 98 / 130 cm³/rev | 262 | 3 | 947070-B |
| PVG-048 / -065 / -075 (B-Frame) | 48 / 65 / 75 cm³/rev | 215 | 2 | 947019B |
| PVG-100 / -130 (C-Frame) | 100 / 130 cm³/rev | 321 | 2 | 947019B |
| PVG-100 / -130 F1U Series | 100 / 130 cm³/rev | 261 | 3 | 947022 |
| PVV-200 / -250 (B1 and B2 Series) | 200 / 250 cm³/rev | 227 | 2 | 947027-A |
| PVV-540 (B1 and B2 Series) | 540 cm³/rev | 184 | 2 | 947027-A |
| PVWH / PVW / PVWW (sizes 04 thru 60) | sizes 04, 06, 10, 11, 15, 20, 25, 34, 45, 60 | 312 | 1 | 947015A |
| PVK-140 / -270 / -370 | 140 / 270 / 370 cm³/rev | 217 | 4 | 947025 |
Not sure which one you have? Read the type code on your Oilgear nameplate: size, design series, seal material, rotation, port arrangement and shaft code, and which of those decide the parts you need. Or start at all Oilgear piston pump catalogs.
Shop by series
- PVM piston pump parts, our deepest Oilgear coverage
- PVWJ and PVWH piston pump parts
- PVG and PVV piston pump parts
- PVWW / PVWC and PVK piston pump parts
Also see the Oilgear pump parts guide covering the PVG, PVWH and PVWJ series.
What we supply
Rotating groups, pistons and shoes, valve plates, swashblocks, saddle bearings, shafts, bearings, control and compensator assemblies, and complete seal kits. Oilgear seal kits · Oilgear piston pump seal kits · All Oilgear parts
Oilgear pump repair
Oilgear units run at high pressure and are usually worth rebuilding rather than replacing, particularly where no current equivalent exists. We do rotating group overhaul, shaft and bearing work, compensator setting and resealing. Evaluation is free and the rebuilt unit carries a 1-year warranty, see hydraulic pump repair and rebuild.
Obsolete Oilgear parts
Much of the Oilgear catalog is discontinued. If the number on your pump returns nothing, send us the model code, the displacement and a photo of the nameplate. We cross reference by dimension and function, hold new old stock and rebuild what cannot be bought. Browse the sourceable part number index.
Have a number to check? Request a quote, email info@restopower.com or call (810) 882-1171.
